How to Work for Stainless Steel Pneumatic Butterfly Valve

Stainless steel pneumatic butterfly valve is used to control the water direction, the circular disc is opened and closed in order to achieve the opening of the pneumatic valve.

The main use of cut-off valve can also be designed to adjust the valve with the adjustment function, the current disc valve is Low-pressure and medium-diameter pipe, is used more and more.

Stainless steel pneumatic butterfly valve parameters:
Valve type: D671F / X, D673H, D373H
Nominal size: DN40 ~ DN2000
Valve Material: cast iron, carbon steel, cast steel, stainless steel and so on
Pressure range: 0.6 ~ 4.0MPa
Applicable temperature: ≤300 ℃
Applicable medium: steam, hot water, acid salt, sewage, smoke, dust and so on
Transmission: Worm, pneumatic, electric, manual, electro-hydraulic

Attachment options:
Adjustable accessories: electrical locator, pneumatic positioner, electrical converters.
Cut-off accessories: single solenoid valve, dual solenoid valve, limit switch back to the message device.
Air handling accessories: air filter regulator, air handling triple pieces.
Manual: HVSD hand-held institutions

The characteristics of stainless steel pneumatic butterfly valve application
The structure of stainless steel butterfly valve itself is compact, is featured by reliable sealing, simple structure, easy maintenance, sealing surface and spherical surface, is often in a closed state, easy to be medium erosion, easy operation and maintenance for water, solvents, acids and natural gas and other general working medium.

Stainless steel pneumatic butterfly valve is also suitable for working conditions of poor media, such as oxygen, hydrogen peroxide, methane and ethylene, to be widely used in various industries. Stainless steel butterfly valve body can be integral, it can be combined.
